Ansible ELK

ELK provisioning through Ansible.

Elasticsearch – It stores incoming logs from Logstash and provides the ability to search the logs/data in real-time.

Logstash – It does the processing (Collect, enrich and send it to Elasticsearch) of incoming logs sent by beats (forwarder).

Kibana – provides visualization of logs.

Pre-requisites

The amount of CPU, RAM, and storage that your Elastic Stack server will require depends on the volume of logs that we intend to gather commonly we are using,

RAM: 4GB

CPU: 2

As Usual, procedurally install Ansible on the local machine. Host details to be entered as,

Ping all the nodes,

[root@localhost ~]# ansible all –m ping

playbooks GitHub link,

https://github.com/Serlya/ELK-multOS

set a host file to connect all nodes.

In this playbook, we were created Elasticsearch Logstash Kibana through ansible playbooks.

First, we created a playbook for ubuntu,

ELK is java based web interface,

- name: Add the Java PPA repo

  apt_repository:

   repo: ppa:webupd8team/java

in this we adding the java repo.

Next, we accepting the license,

- name: Automatically accept the Oracle license

 shell: echo debconf shared/accepted-oracle-license-v1-1 select true | sudo debconf-set-selections

download & install the java,

- name: Install Java 8

  apt:

   name: openjdk-8-jre-headless

   state: present

   update_cache: yes

it automatically sets the java path,

and now adding the Elasticsearch apt-key,

- name: Add Elasticsearch apt key

  apt_key:

   url: "https://packages.elastic.co/GPG-KEY-elasticsearch"

   state: present

#Add the Elasticsearch apt repo. For versions 6 of the stack - use '6.x-prerelease':

- name: Adding Elasticsearch repo

  apt_repository:

   repo: deb https://artifacts.elastic.co/packages/6.x/apt stable main

   state: present

# Installing Elasticsearch

- name: Install Elasticsearch

  apt:

   name: elasticsearch

   state: latest

   update_cache: yes

# Update Elasticsearch config file to allow access (to secure Elasticsearch, bind to 'localhost').

In ansible, there is a linein file command to used to manage lines in text files,

- name: Updating the config file to allow outside access

  lineinfile:

   destfile: /etc/elasticsearch/elasticsearch.yml

   regexp: 'network.host:'

   line: 'network.host: 0.0.0.0'

# Update Elasticsearch port in config file

- name: Updating the port in config file

  lineinfile:

   destfile: /etc/elasticsearch/elasticsearch.yml

   regexp: 'http.port:'

   line: 'http.port: 9200'

# Start Elasticsearch service,

- name: Starting Elasticsearch

  service:

   name: elasticsearch

   state: started

# install logstash

- name: Install Logstash with apt

  apt:

   name: logstash

   state: latest

# copy the configuration files for Logstash,

In this configuration files, location is  master, so we are going to copy to the node,

- name: copy files

      copy: src=/root/ansible-elk-playbook/02-beats-input.conf dest=/etc/logstash/conf.d/02-beats-input.conf

- name: copy filter files

     copy: src=/root/ansible-elk-playbook/10-syslog-filter.conf dest=/etc/logstash/conf.d/10-syslog-filter.conf

- name: copy output file

     copy: src=/root/ansible-elk-playbook/30-elasticsearch-output.conf dest=/etc/logstash/conf.d/30-elasticsearch-output.conf

#start logstash service

- name: Starting logstash

  service:

   name: logstash

   state: started

# Install Kibana

- name: Install Kibana with apt

  apt:

   name: kibana

   state: latest

   update_cache: yes

# Configurations,

- name: Updating the config file to allow outside access

  lineinfile:

   destfile: /etc/kibana/kibana.yml

   regexp: 'server.host:'

   line: 'server.host: 0.0.0.0'

- name: Defining server port

  lineinfile:

   destfile: /etc/kibana/kibana.yml

   regexp: 'server.port:'

   line: 'server.port: 5601'

- name: Defining Elasticsearch URL

  lineinfile:

   destfile: /etc/kibana/kibana.yml

   regexp: 'elasticsearch.url:'

   line: 'elasticsearch.url: "http://localhost:9200"'

Starts the kibana service,

- name: Starting Kibana

  service:

   name: kibana

   state: started

playbook for centos node,

in this playbook for elk provision in centos node,

- name: Add Elasticsearch key

 rpm_key:

  key: "https://packages.elastic.co/GPG-KEY-elasticsearch"

  state: present

adding the elk repos,

- name: copy files

  copy: src=/root/sunita/elk.repo dest=/etc/yum.repos.d

installing the elastic search,

-name: install elasticsearch

 yum:

  name: elasticsearch

  state: latest

  update_cache: yes

Update Elasticsearch config file to allow access

- name: Updating the config file to allow outside access

 lineinfile:

  destfile: /etc/elasticsearch/elasticsearch.yml

  regexp: 'network.host:'

  line: 'network.host: 0.0.0.0'

 - name: Updating the port in config file

  lineinfile:

   destfile: /etc/elasticsearch/elasticsearch.yml

   regexp: 'http.port:'

   line: 'http.port: 9200'

this task to start the elasticsearch service,

- name: Starting Elasticsearch

  service:

   name: elasticsearch

   state: started

install the kibana with yum,

- name: Install Kibana with yum

  yum:

   name: kibana

   state: latest

   update_cache: yes

configurations for kibana,

- name: Updating the config file to allow outside access

  lineinfile:

   destfile: /etc/kibana/kibana.yml

   regexp: 'server.host:'

   line: 'server.host: 0.0.0.0'

 - name: Defining server port

  lineinfile:

   destfile: /etc/kibana/kibana.yml

   regexp: 'server.port:'

   line: 'server.port: 5601'

 - name: Defining Elasticsearch URL

  lineinfile:

   destfile: /etc/kibana/kibana.yml

   regexp: 'elasticsearch.url:'

   line: 'elasticsearch.url: "http://localhost:9200"'

task for starts the kibana service,

- name: Starting Kibana

  service:

   name: kibana

   state: started

next playbook elk provision for windows,

first, install the elasticsearch for windows through chocolatey, there are two ways to download and install the packages,

if you are download from URL it's not working properly better to download from chocolatey with versions,

while installing the packages through chocolatey versions for elasticsearch logstash & kibana must be the same.

- name: elasticsearch

  win_chocolatey:

      name: elasticsearch

      version: 6.2.4

setting configuration files for elasticsearch,

- name: set path for elasticsearch

  win_lineinfile:

      path: C:\ProgramData\chocolatey\lib\elasticsearch\tools\elasticsearch-6.2.4\config\elasticsearch.yml

      regexp: 'path.data:'

      line: 'path.data:C:\ProgramData\chocolatey\lib\elasticsearch\tools\elasticsearch-6.2.4\logs\data'

 - name: set log path elasticsearch

   win_lineinfile:

       path: C:\ProgramData\chocolatey\lib\elasticsearch\tools\elasticsearch-6.2.4\config\elasticsearch.yml

   regexp: 'path.logs:'

   line: 'path.logs:C:\ProgramData\chocolatey\lib\elasticsearch\tools\elasticsearch-6.2.4\logs'

 - name: memory setup

   win_lineinfile:

       path: C:\ProgramData\chocolatey\lib\elasticsearch\tools\elasticsearch-6.2.4\config\elasticsearch.yml

       regexp: 'bootstrap.memory_lock: true'

       line: 'bootstrap.memory_lock: true'

 - name: Updating the config file to allow outside access

   win_lineinfile:

       path: C:\ProgramData\chocolatey\lib\elasticsearch\tools\elasticsearch-6.2.4\config\elasticsearch.yml

       regexp: 'network.host:'

       line: 'network.host: 0.0.0.0'

 - name: Updating the port in config file

   win_lineinfile:

      path: C:\ProgramData\chocolatey\lib\elasticsearch\tools\elasticsearch- 6.2.4\config\elasticsearch.yml

       regexp: 'http.port:'

       line: 'http.port: 9200'

starts the elasticsearch service,

- name: elasticsearch start

  win_command: net start elasticsearch-service-x64

install the kibana

- name: kibana

 win_chocolatey:

   name: kibana

   version: 6.2.4

configuring the kibana config files to access,

- name: Defining server port

  win_lineinfile:

      path: C:\ProgramData\chocolatey\lib\kibana\tools\kibana-6.2.4-windows-x86_64\config\kibana.yml

      regexp: 'server.port:'

      line: 'server.port: 5601'

 - name: Updating the config file to allow outside access

    win_lineinfile:

        path: C:\ProgramData\chocolatey\lib\kibana\tools\kibana-6.2.4-windows-x86_64\config\kibana.yml

        regexp: 'server.host:'

        line: 'server.host: 192.168.1.18'

 - name: Defining Elasticsearch URL

   win_lineinfile:

       path: C:\ProgramData\chocolatey\lib\kibana\tools\kibana-6.2.4-windows-x86_64\config\kibana.yml

       regexp: 'elasticsearch.url:'

       line: 'elasticsearch.url: "http://localhost:9200"'

start the kibana service if error occurs it skips and will go to next task,

- name: kibana service

       win_command: powershell.exe C:\ProgramData\chocolatey\lib\kibana\tools\kibana-6.2.4-windows-x86_64\bin\kibana.bat

       ignore_errors: yes

install the logstash from logstash,

 - name: logstash

   win_chocolatey:

       name: logstash

       version: 6.2.4

edit the config files,

edit the config file in master and copy that files into windows

- name: copy files

  win_copy:

      src: '/home/logstash.conf'

      dest: 'C:\ProgramData\chocolatey\lib\logstash\tools\logstash-6.2.4\bin\logstash.conf'

[root@localhost ~]#cat logstash.conf

input {

 beats {

  port => 5044

 }

}

output {

 elasticsearch {

  hosts => "localhost:9200"

  manage_template => false

  index => "%{[@metadata][beat]}-%{+YYYY.MM.dd}"

  document_type => "%{[@metadata][type]}"

 }

}

Start the Logstash service,

-name: Logstash service

   win_command: powershell.exe C:\ProgramData\chocolatey\lib\logstash\tools\logstash-6.2.4\bin\logstash.bat -f Logstash.conf &

   name: Logstash-6.4

   path: C:\ProgramData\chocolatey\lib\logstash\tools\logstash-6.2.4\bin\logstash.bat -f Logstash.conf

   start_mode: auto

finally to run this playbook,

[root@localhost ~]# nohup ansible-playbook single.yml & > /tmp/nohup.out 2>&1 &

Nohup is short for “No Hangups.” It’s not a command that you run by itself. Nohup is a supplemental command that tells the Linux system not to stop another command once it has started. That means it’ll keep running until it’s done, even if the user that started it logs out.

we need to start the services in the background that's why we used the nohup command,

Check the node IP with elk ports.

http://192.168.1.68:9200

http://192.168.1.68:5601
